OverviewEKRA X5 Professional Screen and Stencil Printer
EKRA X5 Professional is an inline screen and stencil printing platform. This guide separates the published base printer from optional dispensing, inspection, transport and multi-carrier equipment; the manufacturer illustration does not establish the configuration of an offered unit. Select X5 Professional around stencil format, support, deposit quality and full changeover evidence. Do not substitute generic X5, SERIO 4000 or SERIO 8000 specifications, or assign an optional multi-carrier feature from a dealer description.
Manufacturer-published model data
EKRA X5 Professional Technical Specifications
| Brochure printing envelope | 80 × 50 to 508 × 508 mm; identify the required carrier and configuration |
|---|---|
| Brochure stencil frame | 450 × 450 to 740 × 740 mm |
| Brochure substrate thickness | 0.2–5 mm; vacuum support is required for the thin-board condition |
| Alignment repeatability | ±12.5 µm at 6 Sigma; not deposit-volume accuracy |
| Print repeatability | ±20 µm at 6 Sigma under the manufacturer conditions |
| Published cycle | 8–5 seconds plus printing; transport-option dependent, not full-board guaranteed output |
| Brochure machine envelope | 1,180 × 1,866 × 1,470 mm; approximately 980 kg, with drawing/option exclusions |
| Brochure supply | 400 V AC, 50/60 Hz, 3L+N+PE; verify nameplate and installation manual |
Manufacturer model data · Important: model-level figures and features are conditional manufacturer information, not guarantees for a particular used EKRA X5 Professional unit.
Key Features
Configuration Must Be Verified
The offer must identify X5 Professional nameplate, controller/software, stencil frame, clamps/support, squeegees, cleaning and installed options; Labelled paste deposits, alignment repeatability, board transfer, complete print/clean cycle and recipe recovery.
Buyer decision guide
When EKRA X5 Professional Makes Sense — and When It May Not
EKRA X5 Professional selection should begin with production requirements and evidence, not with a model name alone.
Application qualification
EKRA X5 Professional Acceptance Plan
Define the printing task before comparing equipment
Send the stencil-frame dimensions, substrate outline, thickness, mass and underside protrusions with an X5 Professional enquiry. Include the paste or glue system, aperture geometry and the deposit measurements that determine acceptance. A catalogue alignment-repeatability value describes positioning under stated conditions; it does not establish paste height, volume or transfer efficiency. Ask for a supported-board trial with independent deposit inspection and retain the material, stencil, support and settings alongside the measured result.
Identify the exact printer and fitted options
Photograph the X5 Professional nameplate and retain the controller, software and option screens from the offered serial. Generic X5 seller headings and SERIO tables are not sufficient identity evidence. Request isolated views of clamps, supports, squeegee mechanisms, stencil cleaning and any dispensing or post-print inspection equipment. Optilign and multi-carrier capability must be matched to the actual installation and application rather than inferred from the reference picture. Do not assume a license, upgrade or spare-part compatibility from the shared EKRA brand.
Time cleaning, transfer and recovery as well as printing
Run the representative board through loading, alignment, printing, separation and unloading, including the agreed cleaning interval and a realistic changeover. Keep the complete board-cycle trace instead of treating the brochure transfer cycle as production capacity. Inspect cleaning consumables, vacuum performance and support access under the approved safety procedure, then test recoverable recipes and documented maintenance. Leeport and Efficient Technology provide independent China exact-model enquiry channels; neither was contacted. Their service, warranty and availability statements are not proof of the condition or delivery scope of a particular machine.
