JUKI 100-series nozzles
The supplier lists JUKI 101–106 nozzle assemblies with separate ordering codes. Only the 103 reference has a retained photograph here. Use the model mark and full code together; one 100-series photograph cannot describe every pickup face in the family.
Selected part reference
E3503-721-0A0
Confirm the offered item's maker, part code, condition, availability and machine fit before ordering.
103
101
Photo unavailable for this model. Confirm its code and request an exact-item photo.
102
Photo unavailable for this model. Confirm its code and request an exact-item photo.
104
Photo unavailable for this model. Confirm its code and request an exact-item photo.
105
Photo unavailable for this model. Confirm its code and request an exact-item photo.
106
Photo unavailable for this model. Confirm its code and request an exact-item photo.
- Model
- 103
- Part code
- E3503-721-0A0
- Fit
- Confirm by unit
01 / Select precisely
Compare the family variants
Compare complete part numbers, revisions and matching information.
| Model | Part number | Compatibility | Details and checks |
|---|---|---|---|
| 103 | E3503-721-0A0 | Source title identifies the photographed 103 reference; machine/head and component suitability require confirmation. |
|
| 101 | E35017210A0 | Separately listed model; no matched photograph retained. |
|
| 102 | E35027210A0 | Separately listed model; no matched photograph retained. |
|
| 104 | E35047210A0 | Separately listed model; no matched photograph retained. |
|
| 105 | E35057210A0 | Separately listed model; no matched photograph retained. |
|
| 106 | E35067210A0 | Separately listed model; no matched photograph retained. |
|
02 / Check before ordering
Match the installed part
Check the installed code and machine configuration. Similar appearance or a shared series name does not establish interchangeability.
- Keep each model paired with its own ordering code; the 103 title uses E3503-721-0A0.
- Confirm machine and head compatibility with the applicable documentation.
- Specify the component/contact requirement and request the relevant drawing rather than choosing by photograph scale.
- Ask for actual tip, seat and opening photographs and the agreed inspection scope.
03 / Make a useful decision
Selection and replacement advice
Compare the required component contact and pickup opening against the applicable nozzle drawing and head documentation. A family number is a starting point for identification, not a universal component-size recommendation. The source title includes the figures 3.0 and 1.7 without a retained dimensional drawing. Do not turn those figures into approved dimensions or a pickup limit. Quote the exact nozzle and required quantity; clarify whether holders or other accessories are included.
04 / Care and handling
Maintenance and handling guidance
Separate contamination from visible tip damage in the record. A clean-looking surface does not establish an unobstructed path or an acceptable contact face.
Use only the applicable cleaning and inspection method; do not choose a solvent or probe diameter from the family name. Keep each nozzle identity with its assessment.
Before you ask
Questions about this part
Why are some family models shown without photographs?
Their model/code pairs are retained from the source list, but a matched image has not been obtained. The 103 image is not reused as their identity proof.
Keep the part in context
Request a quote for this part
Choose the complete part number and quantity. Continue to our contact form with these details; your inquiry is sent only when you submit that form.
